30m/Min Scrap Copper Wire Stripping Machine 2-120mm Stripping Range

Minimum Order Quantity : 1 set Price : USD 1300-1600 per set
Packaging Details : Ply wooden case Delivery Time : 5 work days
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 100 sets per month
Place of Origin: Zhengzhou, China Brand Name: TMS
Certification: ISO, CE, CO Model Number: QJ-120-2

Detail Information

Name: Scrap Copper Wire Stripping Machine Function: Stripping
Motor: 3kw Stripping Range: 2-120mm
Size: 820*560*1190mm Voltage: 380V/50HZ, 3 Phase
Speed: 30m/min Weight: 236kg
High Light:

30m/Min Scrap Copper Wire Stripping Machine

,

120mm Scrap Copper Wire Stripping Machine

,

120mm cable scrap machine

Product Description

30m/Min Scrap Copper Wire Stripping Machine 2-120mm Stripping Range


Introduction of scrap copper wire stripping machine



Scrap copper wire stripping machine has the most funtions among our stripper machines. This kind stripper is a multi-purpose wire stripper developed by our company for small wires and high-voltage cables, submarine cables and armored cables. It is simple to operate and easy to adjust. It is driven by a 3kW six level three-phase motor.



Technical datas of scrap copper wire stripping machine



Model QJ-120-2
Machine size 820*560*1190mm
Capacity 30m/min
Motor Power 3kw
Weight 236kg
Motor 380V/220V
Wire diameter stripped 2-120mm
Blades 10+2 pcs
Hole 7+1



Feature of scrap copper wire stripping machine



1) This machine suitable for a variety of wire. Wire stripping range 2-120mm.This machine is practicable and easy to handle.

2) Frame dual blades principal, can process different diameter cable, easy to operate and durable.

3) This model are easy to operate, convenient to carry, energy saving, for single copper wire(hard wires) can be rolled or blades stripping, other cables(soft wires) can be easily stripped.



Working principle of copper wire stripper



Before the separation and recycling of the surface layer and the inner core of the waste cable, the connector of the cable should be cut off to ensure the long-term durability of the blade, and then the feeding starts. The surface layer of the cable will be cut by the blade on the machine, and then the cut waste cable will be sent to the roller by the conveyor belt, and the inner core and the surface layer will be separated by the strong extrusion force of the roller, However, starting from the personnel, the surface layer and the inner core should be tied up by classification, which is the complete working principle of the waste cable stripping machine.



Application of copper wire stripping machine



Copper wire stripper can strip three types of wires, one is short wire, the head and tail of short wire are completed through the front wire feeding wheel and front wire pressing. The second is the long line, which only needs to be peeled. The end of the long line is completed by the cooperation of the front wire feeding wheel and the front wire pressing wheel, and the end of the line is completed by the cooperation of the rear wire feeding wheel and the rear wire pressing wheel. The third is sheath, which needs to peel one to three layers of wires. The first three layers of wires are completed through the cooperation of the front wire feeding wheel and the front wire pressing wheel, and the last three layers are completed through the cooperation of the rear wire feeding wheel and the rear wire pressing wheel.



Points for attention in recycling process



1. The blade should not be too sharp to damage the inner core. At the same time, the position of the blade should be set according to different cables.

2. Pay attention to check whether the position is wrong when feeding.

3. Pay attention to whether the pressure of the springs on both sides is too tight, which will cause the cable cannot pass through.



30m/Min Scrap Copper Wire Stripping Machine 2-120mm Stripping Range 0



30m/Min Scrap Copper Wire Stripping Machine 2-120mm Stripping Range 1
