700Kg/H 800kg/H Double Shaft Shredder Machine 50 R/Min Speed

700Kg/H 800kg/H Double Shaft Shredder Machine 50 R/Min Speed

Product Details:

Place of Origin: China
Brand Name: TMS
Certification: ISO, CO, CE
Model Number: TMS-400

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiated
Packaging Details: Ply wooden case with 4200*2300*2700 mm or Full container
Delivery Time: 20 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20 sets per month
Get Best Price Contact Now

Detail Information

Name: Double Shaft Shredder Function: Shred Metals
Machine Size: 1650*900*1600 Motor Power: 18.5kw
Productivity: 700-800kg/h Speed: 50 R/min
Weight: 700kg Voltage: 380 V Or Customized
High Light:

800kg/H Double Shaft Shredder Machine


700Kg/H Double Shaft Shredder Machine


50R/Min Double Shaft Shredder Machine

Product Description

50 R/Min Speed 700 Kg/H 800kg/H Double Shaft Shredder


Introduction of double shaft shredder


Double shaft crusher can meet the requirements of waste recycling in various industries, and is suitable for shredding thicker and refractory materials, such as electronic waste, plastics, metals, wood, waste rubber, packaging barrels, pallets, etc. There are many kinds of recyclable materials. The torn materials can be directly recycled or further refined according to demand. It is suitable for industrial waste recycling, medical treatment recycling, electronic manufacturing, pallet manufacturing, wood processing, domestic waste recycling, plastic recycling, tire recycling, paper making and other industries. This series of double shaft crusher has the characteristics of low speed, high torque and low noise. It adopts PLC control system and can be automatically controlled. It has the functions of starting, stopping, reversing and overloading automatic reversing control.


Specification of double shaft shredder


Model TMS-400
Power 18.5kw
Voltage 380v/50hz
Capacity 700-800kg/h
Speed 50 r/min
Size 1650*900*1600 mm
Weight 700 kg


Features of double shaft shredder


1. The double shaft shredder uses heavy moving knives with high crushing efficiency, and its knives are cast with alloy steel, which is firm and has long service life.

2. The frame plate is thick, can resist high torque, firm and durable.

3. Microcomputer (PLC) automatic control is adopted, with various functions of start, stop, reverse and overload automatic reverse control.

4. It has the characteristics of low speed, large torque, low noise and less dust.

5. Easy adjustment, low maintenance cost, economy and durability.

6. The thickness of the tool and the number of jaws can be changed according to different materials.


Working process of dual shaft shredder


The main working parts of double shaft shredder are a pair of relatively rotating rollers, which are equipped with spirally arranged gear teeth. When the material enters the machine, it is torn and sheared by the teeth of the high hardness wear-resistant material which rotates staggeredly and is splitted, broken and crushed into smaller than the set size, and then forcibly excluded from the machine. Roller driven by motor through reducer has super-large torque, encounter difficult debris, will automatically reverse under the action of PLC automatic control system, and many times positive and negative, until the material is broken and discharged.


Application of dual shaft shredder


The items that can be torn up by metal shredding machine are

(1). Wood processing industry: wooden pallets, branches, seats, wood, roots; Wisconsin environmental protection.

(2). Plastic products industry: mixed plastics, plastic buckets, rubber blocks, nozzle materials, garbage cans.

(3). Waste tire industry: automobile tires, tires with rough steel wire removed, rubber.

(4). Metal recovery industry: scrap iron and steel, lead, aluminum alloy, copper scrap.

(5). Electronic waste industry: electronic appliances, plugs, transformers, air conditioners, induction cookers, television.


700Kg/H 800kg/H Double Shaft Shredder Machine 50 R/Min Speed 0
