100kg/H 200kg/H Metal Shredder Machine Q235 Materials

100kg/H 200kg/H Metal Shredder Machine Q235 Materials

Product Details:

Place of Origin: China
Brand Name: TMS
Certification: ISO, CO, CE
Model Number: SSJ-200

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiated
Packaging Details: Ply wooden case with 4200*2300*2700 mm or Full container
Delivery Time: 10 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20 sets per month
Get Best Price Contact Now

Detail Information

Name: Metal Shredder Machine Function: Shred Metals
Whole Dimension: 1000*920*1270mm Power: 5.5kw
Capacity: 100-200kg/h Blades: 13 Pieces
Weight: 300kg Materials: Q235
High Light:

200kg/H Metal Shredder Machine


100kg/H Metal Shredder Machine


Q235 Metal Shredder Machine

Product Description

Q235 Materials 100kg/H 200kg/H Metal Shredder Machine


Introduction of metal shredder machine


Metal shredder machine is a large and small biaxial shredder equipment with biaxial knife roller doing relative movement to cut or tear up shredded materials. The equipment is mainly composed of knife roller, screen, fixed knife, bearing box, box support, feeding system, power system and electrical control system. Due to its low speed and high torque, the double shaft shredder is suitable for shredding hard or large materials. Such as wood, tires, waste household appliances, metals, etc.

Metal shredder machine is mainly used for coarse powder in waste household appliances, color steel plates, cables, plastics, rubber, ton bags, tires, domestic waste, paper waste and other industries. It is mainly characterized by high output, no dust and low noise. It is an environmental protection processing equipment at present.


Technical data of metal shredder machine




Main body

Model SSJ-200
Body It adopts split type for easy disassembly and assembly, welded by Q235 steel plate.
Dimension 1200*650*1100mm
Power 5.5kw
Reducer BWD4 Cycloid needle
Reducer speed ratio 48.57
Frame 100*100 channel steel welded






Quantity 13 pieces
Cutter head material 9crsi
Cutter head hardness range 53-56
Cutter head diameter 150mm
Cutter head thickness 15mm
Blade type The outer tooth adopts small hook angle outer triangular tooth shape, and the inner hole is hexagonal
No. of cutter head teeth Customized according to customer requirements
Shaft Spindle form Hexagonal shaft
Shaft diameter 70mm
Spacer Quantity 13 pieces
Capacity 100-200kg/h


Advantage of metal shredder


1. The design of the machine is reasonable, and the body is welded with high-quality steel.

2. It is fastened with high-strength screws, with solid structure and durability.

3. The design of the main machine is exquisite, and the broken material adopts the separation design to make its output higher.

4. The processed and broken pieces are uniform and the loss is small. A variety of screens can be replaced at the same time to meet different needs.

5. At the same time, it is equipped with tools of different materials, so that the tools can be retracted and adjusted for different materials, can be grinded after blunt, can be used for many times, and has a long service life.

6. The machine has the advantages of advanced structure, beautiful appearance, simple operation, stable operation, low investment and high efficiency.

7. Equipped with an enlarged pulley to increase the inertia of the crusher, which can save energy and strong crushing.


Application of metal shredder


1. Various hollow containers: plastic beverage cans, plastic barrels, iron barrels, packing boxes, packing barrels

2. Waste household appliances: TV, washing machine, refrigerator shell

3. Pipes: large pipes, pipe fittings, PE pipes

4. Waste formwork: wooden pallet, plastic pallet, forklift pallet

5. Waste tires: car tires, truck tires

6. Waste metal: automobile shell, aluminum alloy, waste aluminum castings, engine shell, lead and steel plate with thickness less than 5mm

7. Food waste, domestic waste, animal corpses, RDF derivatives, medical waste, biological orange stalk, garden waste

8. Rubber head material, paper mill rope.
