Dry Type 300kg/H 400kg/H Copper Wire Granulator Eco Friendly

Dry Type 300kg/H 400kg/H Copper Wire Granulator Eco Friendly

Product Details:

Place of Origin: Zhengzhou, China
Brand Name: TMS
Certification: CO, CE
Model Number: TMS-600

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: One 20 feet container
Delivery Time: 10 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 sets per month
Get Best Price Contact Now

Detail Information

Name: Copper Cable Wire Granulator Function: Recycle Copper Cables
Type: Dry Type Total Power: 49.86kw
Copper Recovery: 99.9% Capacity: 300-400 Kg/h
Total Weight: 3400kg Diameter Of Wire: 0.1-25mm
High Light:

400kg/H Copper Wire Granulator


300kg/H Copper Wire Granulator


400kg/H copper granulator machine

Product Description

Dry Type 300kg/H 400kg/H Copper Cable Wire Granulator

Brife Introduction of copper cable wire granulator


This copper cable wire granulator is used for 1-25mm copper wires and cables. It can deal with 60-100KGS materials in one hour. If the wires/cables is short and diameter less than 10mm. It can deal with 300-400KGS materials in one hour. Have PLC control system(Function: One click Start, One click trun off, AMP monitor, Motor protection and so on)

Copper cable granulator is mainly used to recycle different types of cable wires, such as all kinds of automotive circuit cable lines, communication cable lines and various waste wires that are not suitable to be processed by stripping machines. Like: computer wires, automobile wires, tele-communication cables, electric telephone wires. The functions of these cable recycling system include pre-shredding, steel removal, granulation and separation of plastics from copper or aluminum. The advanced design of these plants results in excellent separation of the different fractions, even when processing mixed cables of varying size and composition.


Technical parameters of copper cable wire granulator
Model Dimension (mm) Total Power (kw) Capacity (kg/h) Weight (kg)
Mini-400 1500*1500*1900 11.92 100 750
TMS-400 2700*1900*2300 23.12 150-200 1200
TMS-600 3980*1950*2216 49.86 300-400 3400
TMS-800 9200*4100*2400 78.76 500-800 8000


Advantages of copper cable wire granulator


1. Eco-friendly equipment: Each copper recycling machine is equipped with a dust collection device, so the recycling process does no harm to environment.
2. Cover a small area: The structure of the machine is compact. In addition, it’s easy to install a copper recycling machine.
3. Easy operation: PLC control system, highly automatic, high efficiency.
4. High-quality spare parts, long service life. The blade is made of high-quality alloy steel.


Precautions during operation


The correct use of copper wire granulator should select the model according to different material properties, which can not only improve the crushing efficiency, but also prolong the service life of the machine. The blade is processed by wire cutting, and the blade is interchangeable.

For different lines, we have different requirements for the blade of the machine.

1. Wool wire and multi strand wire: when processing wool wire and multi strand wire, the fixed knife and moving knife of the copper wire granulator shall be sharp, and the broken wire shall be cut off by the blade, so that the copper rice is clean and high purity.

2.Single strand and single core wire: when handling single strand and single core wires, the blade edge of the moving knife is required to be blunt and the fixed knife is required to be sharp. Under this requirement, the spacing between the moving knife and the fixed knife is that the single strand cable just blocks the cable and does not contact the wire core. At this time, the cable is broken by inertia, which can effectively avoid copper wrapping.
