230mm Flat Die 300-400 Kg/H Feed Pellet Mill Machine

230mm Flat Die 300-400 Kg/H Feed Pellet Mill Machine

Product Details:

Place of Origin: Zhengzhou, China
Brand Name: TMS
Certification: CE, ISO
Model Number: 230

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD1430-1490 per set
Packaging Details: Exported ply wooden case for pellet mill machine
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 60 sets per month
Get Best Price Contact Now

Detail Information

Name: Pellet Mill Machine Function: Making Pig Feed
Productivity: 300-400kg/h Power Supply: 11kw
Machine Dimension: 1180*540*1000mm Material Water: 10-18%
Die Plate: Flat Die G. W: 320kg
High Light:

400Kg/H Feed Pellet Mill Machine

,

300Kg/H Feed Pellet Mill Machine

,

300Kg/H poultry feed pellet machine

Product Description

230mm Flat Die 300-400kg/H Pellet Mill Machine



Description of pellet mill machine



Pellet mill machine is a conventional machine specialized in making pellet feed. It covers a small area and can meet the feed demand of the breeding plant. At the same time, the pressed feed pellet has high hardness, internal ripening, and is convenient for animals to eat. It is widely used in pellet feed pressing for pigs, cattle, sheep and other livestock. Some farmers purchase small-sized feed pellets and choose to use them at the same time The small aperture grinding plate makes the feed particles small, which can be used for feeding small head animals such as chickens, ducks, fish, pigeons, rabbits, etc. for some users who need granular fertilizer, they can also press the materials into granular fertilizer, which can be used to fertilize crops or flowers.



Technical parameters of pellet mill machine



Model Power Output (kg/h) Dimension (mm) G.W N.W Moisture required
120 2.2/3kw 60-100 750*320*680 100kg 80kg 10-18%
150 4kw 90-120 800*450*700 110kg 91kg 10-18%
200 7.5kw 200-300 1050*480*990 230kg 200kg 10-18%
230 11kw 300-400 1180*540*1000 320kg 290kg 10-18%
260 15kw 400-600 1240*540*1000 360kg 320kg 10-18%
300 22kw 600-800 1300*560*1100 450kg 410kg 10-18%
400 30kw 800-1200 1560*640*1400 700kg 660kg 10-18%



Feature of pellet mill machine



1. The utility model has the advantages of novel structure, simple operation, wide adaptability, small floor area and low noise.

2. Powder feed and grass powder can be pelletized without adding or a little liquid, and part of moisture will be lost during granulation process, so the moisture content of pellet feed is lower than that of material before granulation, which is more convenient for storage.

3. Chicken, duck, fish, etc. can obtain higher economic benefits than the mixed powder feed.

4. Dry material processing can produce feed particles with high hardness, smooth surface and internal ripening, which can improve the digestion and absorption of nutrients.

5. It can be produced with adjustable length and diameter of Φ 3 mm-6 mm. Grass powder particles, grain grains and mixture particles can be processed.

6. The process of granule formation can denaturate the trypsin resistance factors in grains and beans, reduce the adverse effects on digestion, kill various parasitic eggs and other pathogenic microorganisms, and reduce various kinds of raw insects and digestive system diseases.



Working process of pellet mill machine



The principle of feed pellet machine is simple, and the accessories of conventional pellet machine mainly include: motor, coupling, reducer, spindle, press roll, die plate, hopper, discharge port, control box, etc.

After the power supply is connected, the feed pellet machine is started through the control box. At this time, the motor rotates, and the reducer is driven to rotate through the coupling, thus driving the spindle to rotate. The press roll is fixed on the main shaft, and the press roll rotates with it to fit the die plate. When the material enters the machine body through the hopper, it is extruded through the gap between the pressure roller and the die plate, and then is extruded through the die plate hole. The feed pellet machine has few components and is mainly based on the principle of circular motion. The operation process is simple and easy to operate.
