400Kg/H 600kg/H Flat Die 260mm Biomass Pellet Machine

400Kg/H 600kg/H Flat Die 260mm Biomass Pellet Machine

Product Details:

Place of Origin: Zhengzhou, China
Brand Name: TMS
Certification: CE, ISO
Model Number: 260

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD1860-1990 per set
Packaging Details: Exported ply wooden case for biomass pellet machine
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 sets per month
Get Best Price Contact Now

Detail Information

Name: Biomass Pellet Machine Function: Making Pig Feed
Productivity: 400-600kg/h Power Supply: 15kw
Machine Size: 1240*540*1000mm Moisture Required: 10-18%
Die: Flat Die Gross Weight: 320kg
High Light:

400Kg/H Biomass Pellet Machine


600kg/H Biomass Pellet Machine


600kg/H biomass pellet making machine

Product Description

400 Kg/H 600kg/H Flat Die 260mm Biomass Pellet Machine


Description of biomass pellet machine


Biomass pellet machine is a kind of feed processing machinery which uses corn, soybean meal, straw, grass and rice husk as raw materials and directly pressed into pellets after crushing raw materials. It is mainly used in grain and feed processing plants, animal farms, poultry farms, individual farmers and small and medium-sized farms, farmers or large, medium and small-sized feed processing plants. According to different raw materials and uses, feed pellet processing machinery is also known as straw feed pellet machine, small feed pellet machine, breeding feed pellet machine, household pellet processing equipment, pig feed pellet machine and so on. Feed pellet processing machinery is recognized by more and more farmers.

Generally speaking, today's pellet processing machinery are dry in and dry out, without drying this step, it is more convenient for customers. The machine is mainly used in rabbit industry, fish, duck, chicken, shrimp, pig, cattle, sheep, and industrial granule processing, widely used in industry, organic fertilizer granule, sawdust granule, etc.

During the pressing process of pellet processing machinery, the temperature of the pellet out of the machine should be about 60 ℃, which can be ripened deeply, and the maximum temperature should not exceed 80 ℃. Otherwise, all kinds of trace elements added in the pelleting process will suffer losses, which can not guarantee the feeding needs of livestock and poultry.


Technical parameters of feed pellet machine


Model Power Output (kg/h) Dimension (mm) G.W N.W Moisture required
120 2.2/3kw 60-100 750*320*680 100kg 80kg 10-18%
150 4kw 90-120 800*450*700 110kg 91kg 10-18%
200 7.5kw 200-300 1050*480*990 230kg 200kg 10-18%
230 11kw 300-400 1180*540*1000 320kg 290kg 10-18%
260 15kw 400-600 1240*540*1000 360kg 320kg 10-18%
300 22kw 600-800 1300*560*1100 450kg 410kg 10-18%
400 30kw 800-1200 1560*640*1400 700kg 660kg 10-18%


Features of biomass pellet machine


1. The carburizing treatment is adopted for the gear of the pellet machine to enhance the wear resistance, and the normalizing heat treatment after water forging improves the hardness of the tooth surface

2. The main shaft is processed by water forging, rough turning, heat treatment, fine turning and fine grinding, which improves the fatigue resistance and wear resistance of the components

3. The machine uses the silent bearing, and increases the thin oil circulation cooling lubrication system, the bearing service life is longer, the movement is more stable

4. Powder feed and grass powder can be pelletized without adding or a little liquid, and part of moisture will be lost during granulation process, so the moisture content of pellet feed is lower than that of material before granulation, which is more convenient for storage.
