300-400kg/H Scrap Metal Recycling Machine For 0.1-20mm Wire

300-400kg/H Scrap Metal Recycling Machine For 0.1-20mm Wire

Product Details:

Place of Origin: Zhengzhou, China
Brand Name: TMS
Certification: CE, ISO
Model Number: TMS-600

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiated
Packaging Details: Full container 20'GP or 40'GP for scrap metal recycling machine
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets per month
Get Best Price Contact Now

Detail Information

Name: Scrap Metal Recycling Machine Function: Recycling Copper Wires
Capacity: 300-400kg/h Total Power: 48.36kw
Diameter Range Of Wire: 0.1-25mm Machine Size: 3980*1950*2216mm
Blades: 10+4 Pieces Weight: 3400kg
High Light:

400kg/H Scrap Metal Recycling Machine


300kg/H Scrap Metal Recycling Machine


20mm Wire Scrap Metal Recycling Machine

Product Description

300-400kg/H Scrap Metal Recycling Machine For 0.1-20mm Wire


Description of scrap metal recycling machine


Scrap metal recycling machine is a professional production line for dry separation of waste wires and cables. For example: old car circuit line, communication cable, And the wire stripper is not suitable for processing (all kinds of civil wires) waste miscellaneous wires, wool thin wires, etc. This machine is characterized by that the large and small wires can be broken and separated at the same time without classification, with new and unique structure, large production capacity and low power consumption. It has high sorting rate, one feeding and multi machine cooperation. The whole line is controlled by PLC, which is at the leading level in China. The successful development of this machine solves the problems in the method of burning copper It can also improve the quality of recycled copper, recycle plastics and solve environmental pollution at the same time.


Technical data of scrap metal recycling machine


Machine size 3980*1950*2216mm
diameter range of wire processed 0.1-25mm
Capacity 300-400kg/h
Total Power 48.36kw
Blades 10+4 pieces
Weight  3400kg
Voltage 380V/50HZ or Customized


Features of scrap metal recycling machine


After the crushing and processing of waste wires and cables, the fully automatic mechanical separation can completely separate copper and plastic, achieve the purpose of comprehensive utilization, and have high economic benefits. And no dust, no secondary pollution In addition, the equipment is an integral combined structure, which is convenient for installation, commissioning and transportation (the production can be carried out after the customer purchases the power supply), and the performance is stable.


1. Compact structure, beautiful appearance, reasonable layout and convenient installation.

2. PLC control is adopted to make the equipment feed evenly and operate intelligently, which makes the operation easier, worry-saving, time-saving and labor-saving, and ensures the stable operation of the equipment to the greatest extent.

3. The crusher adopts counter roll type, with low speed, high torque, large output, low noise and simple operation.

4. The crusher, sorting equipment and dust collection equipment adopt the platform combination type, which makes the equipment easy to move and transport and increases the flexibility of the equipment.

5. The rotor of the crusher adopts alternating cutter shaft, which makes the crusher more efficient, lower noise and more stable operation.

6. The separation rate of air separation equipment is as high as 97 ~ 99%.

7. The return system makes the semi-finished products undergo secondary crushing to ensure the complete separation of metal and non-metal.

8. Bag dust collection equipment can effectively control dust overflow, and the dust removal efficiency is up to 99.99%.


300-400kg/H Scrap Metal Recycling Machine For 0.1-20mm Wire 0
